Ball Screws
Linear Guide & Ball Screw Series
Product overview
Ball nuts for recirculating ball screw systems, available in multiple flange and compact configurations matched to screw diameter and lead. This page is prepared for model identification, preliminary selection and quotation. The exact production configuration should be confirmed before order placement.
60 standard modelsKey features
- Multiple nut body/flange styles
- Low-friction recirculating ball design
- Preload options by configuration
- Matched screw-and-nut assemblies available
Standard & custom
Stock standard sizes plus drawing-based variants.
Matched supply
Mating parts supplied together to guarantee fit.
Inspected before shipment
Critical dimensions checked; reports on request.
Specifications
Models & specifications
Values are nominal; confirm final dimensions against the approved drawing.
| Model | Nut Family | Screw Diameter | Lead | Nut Style | Preload | Accuracy / Preload |
|---|---|---|---|---|---|---|
| SFU8010 | SFU | 80 mm | 10 mm | Flange single-nut family | Standard / preload option by requirement | - |
| SFU6310 | SFU | 63 mm | 10 mm | Flange single-nut family | Standard / preload option by requirement | - |
| SFU5010 | SFU | 50 mm | 10 mm | Flange single-nut family | Standard / preload option by requirement | - |
| SFU4010 | SFU | 40 mm | 10 mm | Flange single-nut family | Standard / preload option by requirement | - |
| SFU4005 | SFU | 40 mm | 5 mm | Flange single-nut family | Standard / preload option by requirement | - |
| SFU3210 | SFU | 32 mm | 10 mm | Flange single-nut family | Standard / preload option by requirement | - |
| SFU3205 | SFU | 32 mm | 5 mm | Flange single-nut family | Standard / preload option by requirement | - |
| SFU2510 | SFU | 25 mm | 10 mm | Flange single-nut family | Standard / preload option by requirement | - |
| SFU2505 | SFU | 25 mm | 5 mm | Flange single-nut family | Standard / preload option by requirement | - |
| SFU2010 | SFU | 20 mm | 10 mm | Flange single-nut family | Standard / preload option by requirement | - |
| SFU2005 | SFU | 20 mm | 5 mm | Flange single-nut family | Standard / preload option by requirement | - |
| SFU1610 | SFU | 16 mm | 10 mm | Flange single-nut family | Standard / preload option by requirement | - |
| SFU1605 | SFU | 16 mm | 5 mm | Flange single-nut family | Standard / preload option by requirement | - |
| SFU1204 | SFU | 12 mm | 4 mm | Flange single-nut family | Standard / preload option by requirement | - |
| SFK1402 | SFK | 14 mm | 2 mm | Miniature compact family | Standard / preload option by requirement | - |
| SFK1202 | SFK | 12 mm | 2 mm | Miniature compact family | Standard / preload option by requirement | - |
| SFK1002 | SFK | 10 mm | 2 mm | Miniature compact family | Standard / preload option by requirement | - |
| SFK0802 | SFK | 8 mm | 2 mm | Miniature compact family | Standard / preload option by requirement | - |
| SFK0601 | SFK | 6 mm | 1 mm | Miniature compact family | Standard / preload option by requirement | - |
| SFE4040 | SFE | 40 mm | 40 mm | High-lead flange family | Standard / preload option by requirement | - |
| SFE3232 | SFE | 32 mm | 32 mm | High-lead flange family | Standard / preload option by requirement | - |
| SFE2525 | SFE | 25 mm | 25 mm | High-lead flange family | Standard / preload option by requirement | - |
| SFE2020 | SFE | 20 mm | 20 mm | High-lead flange family | Standard / preload option by requirement | - |
| SFE1616 | SFE | 16 mm | 16 mm | High-lead flange family | Standard / preload option by requirement | - |
| DFU5010 | DFU | 50 mm | 10 mm | Double-nut family | Standard / preload option by requirement | - |
| DFU4005 | DFU | 40 mm | 5 mm | Double-nut family | Standard / preload option by requirement | - |
| DFU3205 | DFU | 32 mm | 5 mm | Double-nut family | Standard / preload option by requirement | - |
| DFU2505 | DFU | 25 mm | 5 mm | Double-nut family | Standard / preload option by requirement | - |
| DFU2005 | DFU | 20 mm | 5 mm | Double-nut family | Standard / preload option by requirement | - |
| DFU1605 | DFU | 16 mm | 5 mm | Double-nut family | Standard / preload option by requirement | - |
| SFU8010 | SFU | 80 mm | 10 mm | Flange single-nut family | - | Rolled / ground and preload options by requirement |
| SFU6310 | SFU | 63 mm | 10 mm | Flange single-nut family | - | Rolled / ground and preload options by requirement |
| SFU5010 | SFU | 50 mm | 10 mm | Flange single-nut family | - | Rolled / ground and preload options by requirement |
| SFU4010 | SFU | 40 mm | 10 mm | Flange single-nut family | - | Rolled / ground and preload options by requirement |
| SFU4005 | SFU | 40 mm | 5 mm | Flange single-nut family | - | Rolled / ground and preload options by requirement |
| SFU3210 | SFU | 32 mm | 10 mm | Flange single-nut family | - | Rolled / ground and preload options by requirement |
| SFU3205 | SFU | 32 mm | 5 mm | Flange single-nut family | - | Rolled / ground and preload options by requirement |
| SFU2510 | SFU | 25 mm | 10 mm | Flange single-nut family | - | Rolled / ground and preload options by requirement |
| SFU2505 | SFU | 25 mm | 5 mm | Flange single-nut family | - | Rolled / ground and preload options by requirement |
| SFU2010 | SFU | 20 mm | 10 mm | Flange single-nut family | - | Rolled / ground and preload options by requirement |
| SFU2005 | SFU | 20 mm | 5 mm | Flange single-nut family | - | Rolled / ground and preload options by requirement |
| SFU1610 | SFU | 16 mm | 10 mm | Flange single-nut family | - | Rolled / ground and preload options by requirement |
| SFU1605 | SFU | 16 mm | 5 mm | Flange single-nut family | - | Rolled / ground and preload options by requirement |
| SFU1204 | SFU | 12 mm | 4 mm | Flange single-nut family | - | Rolled / ground and preload options by requirement |
| SFK1402 | SFK | 14 mm | 2 mm | Miniature compact family | - | Rolled / ground and preload options by requirement |
| SFK1202 | SFK | 12 mm | 2 mm | Miniature compact family | - | Rolled / ground and preload options by requirement |
| SFK1002 | SFK | 10 mm | 2 mm | Miniature compact family | - | Rolled / ground and preload options by requirement |
| SFK0802 | SFK | 8 mm | 2 mm | Miniature compact family | - | Rolled / ground and preload options by requirement |
| SFK0601 | SFK | 6 mm | 1 mm | Miniature compact family | - | Rolled / ground and preload options by requirement |
| SFE4040 | SFE | 40 mm | 40 mm | High-lead flange family | - | Rolled / ground and preload options by requirement |
| SFE3232 | SFE | 32 mm | 32 mm | High-lead flange family | - | Rolled / ground and preload options by requirement |
| SFE2525 | SFE | 25 mm | 25 mm | High-lead flange family | - | Rolled / ground and preload options by requirement |
| SFE2020 | SFE | 20 mm | 20 mm | High-lead flange family | - | Rolled / ground and preload options by requirement |
| SFE1616 | SFE | 16 mm | 16 mm | High-lead flange family | - | Rolled / ground and preload options by requirement |
| DFU5010 | DFU | 50 mm | 10 mm | Double-nut family | - | Rolled / ground and preload options by requirement |
| DFU4005 | DFU | 40 mm | 5 mm | Double-nut family | - | Rolled / ground and preload options by requirement |
| DFU3205 | DFU | 32 mm | 5 mm | Double-nut family | - | Rolled / ground and preload options by requirement |
| DFU2505 | DFU | 25 mm | 5 mm | Double-nut family | - | Rolled / ground and preload options by requirement |
| DFU2005 | DFU | 20 mm | 5 mm | Double-nut family | - | Rolled / ground and preload options by requirement |
| DFU1605 | DFU | 16 mm | 5 mm | Double-nut family | - | Rolled / ground and preload options by requirement |
Typical applications
CNC axesAutomation systemsPositioning stagesMachine tools
Selection guide
- Confirm the transmission type, load, speed and duty cycle.
- Choose model / module / pitch and the matching mating part (chain–sprocket, rack–pinion, belt–pulley, rail–block).
- Specify bore, keyway, length, material, heat treatment and surface finish.
- Send drawings or samples for non-standard parts; we confirm feasibility and quote.
Have a drawing, sample or model number?
Send it to our engineering team — we confirm the specification and reply with a quotation.
